Wakeboard | NIP
- Name | Nip
- Wakeboards / Wakeboard NIP
- Style / Wakepark riding – obstacles
- Rocker / Continuous
- Sizes / 135, 138, 142, 146
A: 1350 mm, B: 430mm, C: 405,6 mm
A: 1380 mm, B: 434mm, C: 424,6 mm
A: 1420 mm, B: 438 mm, C: 450 mm
Price / 11.900 Kč vč. DPH / 466 EUR vč. DPH
- Best choice for your everyday ride in the park. A responsive board boasting great stability on obstacles.
The right weapon for everyday riding in the Park.
We were studying the requests of professional wake park riders and discovered that there is a need to combine stability over obstacles, big pop and great manoeuvrability.
The progressive shape of the bottom pushes water towards the centre of the tail offering a great pop for your tricks. This special bottom profile is deeper at the tips and gets almost flat in the middle, thus offering sufficient stability when sliding over obstacles. Our boards use quadraxial lamination to achieve optimum stiffness. To improve the transfer of tip to tail force, which is needed for the ultimate ollie, our boards are fitted with carbon reinforcements. We're using high-quality base materials typical for winter equipment and known for their durability. The shape of the top side offers a compromise between edge durability and effective edging. The core consists of light paulownia and hard beech stringers which form the centre of the board. Inserts are protected from being ripped out by hard wood and special carbon reinforcements. The handmade pedigree of the board is underlined by a handwritten serial number and a signature of the employee who made it.
- Core | 3d machined woodcore
- Bottom | Hydrodynamic bottom contour - wake specific
- Materials | quadraxial fiberglass
- Reinforcements | Carbon power stringers
- Edge | Rubber dampened edge
- Sidewall construction | Genius sidewall
- Base | Slide base
- Inserts | Bombproof inserts
3d machined woodcore
The core is CNC machined with an accuracy of 0.1 mm. This accuracy allows us to fine-tune the riding performance of our products.
Hydrodynamic bottom contour – wake specific
The profile of the 3D shape is designed with a view to its hydrodynamic properties needed for riding over obstacles.
Quadraxial fibreglass is woven from fibres with 4 different orientations. We have it custom-made so that we're able to fine-tune the board's flex and torsion by choosing the correct weight and thickness of the individual directions of fibres.
Carbon power stringers
Reinforcements from uni-directional carbon fibres improve the flex along the long axis of the board. Their position, weight and width help to optimize the performance.
Rubber dampened edge
To improve shock absorption and increase durability, we use VDO anti-vibration rubber on the joints of the base and the ABS sidewall.
The sidewall is sanded in different ratios and angles to achieve more effective turning and quicker response.
The sintered slide base was specially designed for wakeboarding and has a hardness of 9.2 x 10⁶ mol.
The inserts are placed in beech stringers passing through the core. Moreover, they are reinforced with quadraxial carbon fabric.
